taraSMART
- Tried and tested technology, modern design
- Possible to route connectors such as HDMI, DVI, or network adapters
- Quick and easy assembly
Product description
taraSMART is a sophisticated suspension arm system for modern machine construction. The perfect symbiosis of technical design and sophistication. It offers sufficient space for routing HDMI or DVI cables, or network plugs. Installation is quick and easy, thanks to the familiar, tried and tested technology. The coupling variants of the system enable the connection of both narrow and deep control enclosures. Thanks to the Ø48 bracket, the straightforward connection of panel PCs with a round tube frame can take place without additional adapters.
Product overview
| Image | Article name | Type | Article number | Length | Width | Height | Request | Details |
|---|---|---|---|---|---|---|---|---|
 | taraSMART | Socket joint | 141.005.000 | - | - | - | Details | |
 | taraSMART | Socket joint, vertical | 141.005.001 | - | - | - | Details | |
 | taraSMART | Wall joint | 141.010.000 | - | - | - | Details | |
 | taraSMART | Wall joint, vertical | 141.010.001 | - | - | - | Details | |
 | taraSMART | Intermediate joint | 141.015.000 | - | - | - | Details | |
 | taraSMART | Elbow profile | 141.020.000 | - | - | - | Details | |
 | taraSMART | Elbow Ø48 | 141.020.001 | - | - | - | Details | |
 | taraSMART | Base | 141.030.000 | - | - | - | Details |
Technical data
| Principle | Economic, compact and elegant designer suspension arm system for light to medium loads |
| Additional information | Connection of HMI/control enclosures from leading manufacturers with a round tube frame (such as Siemens, Beckhoff, B&R) possible |
| The generous cable routing offers an optimum connection with all interfaces, sufficient space is available for a range of cables and connectors | |
| Horizontal alignment of the complete system assembly possible at all joints! | |
| Material/coating | Die-cast aluminium alloy, powder coated RAL 7035 |
| Optional: Special colours | |
| Support profiles: Extruded aluminium profile, silver anodised | |
| Ø48 round tubes: steel, silver coated | |
| Covers: Thermoplast, RAL 7016 | |
| Gasket | Chloroprene O-ring gasket (CR) |
| Cable routing | Suitable for HDMI, patch cables, DVI, USB, cold-device plugs, etc. |
| Ingress protection | IP 54 / EN 60529 |
| ROLEC service | Avail of our Full Service Offer for installation-ready products |
| Configuration | To configure this product, please use our practical taraSMART configurator |
Application examples
Frequently Asked Questions
Yes. ROLEC offers various options for customizing the color of your enclosures, HMI enclosures, and support arm systems.
Depending on the application, the following options are available, among others:
• Powder coatings in nearly all RAL colors
• 2K wet paint finishes
• Highly weather-resistant coatings
• Surface treatments such as SurTec 650
The appropriate coating depends on the environmental conditions and your design requirements.
Yes. We’d be happy to provide you with a sample of our products upon request.
In addition, we support you in the development of prototypes and manufacture them, including machining, labeling, or custom features. This allows you to reliably test fit and function even before mass production begins.
Yes. Given the wide variety of enclosure series, materials, and configuration options, we definitely recommend a personalized consultation.
Our experts will help you select the right enclosure solution and guide you from the initial idea to the finished product. In many countries, we also offer on-site consultations. Find your personal contact here.
Yes. Thanks to their modular design, ROLEC support arm systems can be expanded, modified, or adapted to new requirements at any time.
This simplifies modernization efforts and protects your investment in the long term.
Yes. ROLEC support arm systems are based on a modular design and can be customized to suit your specific application.
Possible configurations include, among others:
• Various tube lengths
• Wall, floor, or machine mounts
• Angle and coupling elements
• Different boom arms
• Custom combinations of multiple support arm segments
• How can control panels be positioned ergonomically?
Thanks to the modular joint and coupling elements, control panels can be flexibly aligned and adapted to the respective workstation. This enables ergonomic operation and significantly improves user comfort. Feel free to use our handy support arm configurator.
Yes. Many ROLEC mounting arm systems can also be combined with enclosures or control units from other manufacturers.
Depending on the application, VESA mounts or custom adapter solutions—such as those for 48-mm-diameter round tubing—are available. We’d be happy to check the compatibility of your existing components.
ROLEC's support arm systems are optimally designed to complement the company's HMI enclosure series.
These include, among others:
• profiPANEL
• multiPANEL
• profiCASE
• commandCASE
Depending on the enclosure series, suitable mounting solutions are available for wall, floor, or support arm mounting.
Yes. ROLEC cable support arm systems are designed so that cables can be easily installed and, if necessary, added or replaced at a later date.
This makes it particularly efficient to carry out expansions or service work.
The cable passages in ROLEC support arm systems provide ample space for numerous power and data cables.
Depending on the system, the following cables, among others, can be safely routed:
- Power supply
- Ethernet
- Profinet
- USB
- HDMI
- DVI
- DisplayPort
- Fieldbus cables
The maximum load capacity depends on the selected support arm system, the boom length, and the specific installation situation.
ROLEC offers solutions for both lightweight control devices and heavy-duty HMI and industrial PC systems. Our experts will assist you in selecting the appropriate support arm configuration and verify the permissible loads for your application.
Yes. The profiPLUS 50 and profiPLUS 70 support arm systems feature integrated equipotential bonding across all system components. This ensures a permanently safe electrical connection throughout the entire support arm system—without the need for additional grounding wires between the individual elements. For the protection of people and machines.
ROLEC offers perfectly coordinated HMI enclosures and mounting arm systems—all from a single source.
Depending on the application, the following systems are used:
• profiPLUS 50 – Designer support arms for light to medium loads
• profiPLUS 70 – Designer support arms for medium to heavy loads
• taraSMART – Modern support arm system with integrated cable routing
• taraPLUS – cost-effective solution for numerous industrial applications
• QUADRO 50 – robust support arm system for medium loads
• QUADRO 80 – robust support arm system for heavy loads
Our support arm systems enable secure cable routing, high stability, and ergonomic positioning of control devices. We’d be happy to assist you in selecting the right combination of enclosure and support arm.
