QUADRO 80
The stable support arm system
IP 54
The most important product features:
• Profile cross-sections: square 80 mm
• System parts material: diecast aluminum/spheroidal graphite iron, powder coating, RAL 7040
• Suspension profile material: drawn steel, powder coating, RAL 7035
• Various connections available
• Can be used with all ROLEC control enclosures
• Possible to route connectors such as HDMI, DVI, network adapters, etc.
• Gasket: chloroprene (CR)
Request offer
PDF datasheet
More
QUADRO 80 gets its name from the 80 mm square steel profiles which form the basis of the system. Connection joints and couplings are made of high load spheroidal graphite which provides a higher than average bearing strength. The overall static equilibrium of the system is extremely high due to its use of steel profiles.
QUADRO can be assembled quickly and easily at the point of use, thanks to its sophisticated technology. The articulated parts are equipped with a swivel limiter. A control lamp adapter completes the extensive package. Compatible command enclosures include commandCASE, aluFACE und profiPANEL.
System elements
Choose the right “starting component” for your suspension arm here.
Support profiles
Support profiles are available in four standard lengths from stock, or precisely to the millimetre in accordance with your requirements.
Adaptors
Using the correct adaptors, you can connect every conceivable panel to the QUADRO system.
Couplings
Complement your system with suitable elbows and couplings.
A = Adjustable
A = Adjustable
Product overview
Dimensions
Data Sheets
Data
| Load-bearing capacity |  |
| Principle | Closed system with easy access to system parts for heavy loads |
| Additional info | Simple alignment of the system |
| Heavy-duty system parts made from spheroidal graphite | |
| Signal light adapter available for the elbow | |
| Compatible ROLEC control enclosures: commandCASE, aluFACE, profiPANEL | |
| Material/coating | System elements: Aluminum and high-tensile spheroidal graphite |
| Powder coating RAL 7040, window gray | |
| Optional: Special colors | |
| Supportprofile: Steel, drawn | |
| Powder coating RAL 7035, light gray | |
| Optional: Special colors | |
| Bellows: PVC, RAL 7035, light gray | |
| Cable routing | Suitable for HDMI, patch cables, USB etc., not suitable for DVI plugs |
| Ingress protection | IP 54 / EN 60529 |
| Torque for cutting ring screws | 30 Nm = 3 kg/m |
